One Plus Nord CE5 (8 + 256GB) - Global Version - TRCSL Approved (Pre-Order)

Dimensions

·         Height: 163.58 mm

·         Width: 76.02 mm

·         Thickness:8.27 mm (Marble Mist), 8.17 mm (Black Infinity)

·         Weight: Approx. 199g

·         Size: Marble Mist: 163.58×76.02×8.27 mm, Black Infinity: 163.58×76.02×8.17 mm



Display

Screen Size

·         6.77" (measured diagonally from corner to corner)



Resolution:

·         2392×1080, 387 PPI



Screen-to-body Ratio:

·         94.10%



Aspect Ratio:

·         19.9:9



HBM:

·         1300 nits



Peak Brightness

·         1430 nits



Typical brightness:

·         800 nits



Refresh Rate:

·         120Hz



Touch Response Rate:

·         Up to 300Hz (OTA support), default 120Hz



Others:

·         Support sRGB, Display P3, 10-bit Color Depth, HDR10+,

·         Netflix HD&HDR Certified

·         Amazon Prime Video HD&HDR Certified



Features

·         Eye Comfort / Night Mode

·         Screen Colour Mode

·         Screen Colour Temperature

·         Auto Brightness

·         Manual Brightness

·         Bed time mode

·         Dark Mode



Performance

Operating System:

·         OxygenOS 15.0 based on Android™ 15



Processing Platform:

·         MediaTek Dimensity 8350 Apex



CPU:

·         Arm® cortex 1xA715@3.35GHZ

·         Arm® cortex 3xA715@3.2GHZ

·         Arm® cortex 4xA510@2.2GHZ



GPU:

·         Arm® G615 MC6



RAM:

·         LPDDR5X 8GB-4266MHz



Virtual RAM Expansion:

·         3 expansion options

·         8GB + 4/6/8GB



ROM:

·         128GB / 256GB UFS3.1



Supported expansion card:

·         Yes, up to 1TB MicroSD



Available configurations:

·

·         8GB+256GB



Vibration:

·         Rotor motor



Certification:

·         TÜV SÜD 72-month fluency rating A



Battery & Charge

Battery:

·         7100mAh lithium-ion polymer battery



Charge:

·         80W SUPERVOOC



Camera



Main Camera

Sensor:

·         Sony LYT-600



Sensor Size:

·         1/1.95"



Megapixels:

·         50MP



Focal Length:

·         26 mm equivalent



FOV:

·         79°



Focus mode:

·         Contrast detection autofocus, Phase detection autofocus



Pixel Size:

·         0.8 micron



Aperture:

·         f/1.8



EIS support:

·         Supported



OIS support:

·         Supported



Ultra-Wide Camera

Sensor:

·         OmniVision OV08D10



Sensor Size:

·         1/4"



Megapixels:

·         8 MP



Focal Length:

·         16 mm equivalent



FOV:

·         112°



Focus mode:

·         Fixed focus



Pixel Size:

·         1.12 microns



Aperture:

·         f/2.2



Flash:

·         LED Flash



Zoom:

·         0.6x-20x digital zoom for photos

·         0.6x-10x digital zoom for video



Rear Camera Video:

·         EIS/OIS video: 4K 60fps, 4K 30fps, 1080P 60fps, 1080P 30fps, 720P 30fps

·         SLO-MO: 720p 960fps, 720P 240fps, 1080P 480fps, 1080P 120fps

·         TIME-LAPSE: 1080P 30fps



Rear Camera Features:

·         Photo, Video, Portrait, Night, PRO, Panorama, SLO-MO, Dual-view video, Time-lapse, Hi-Res Scan, Tilt-Shift



Front Camera:

·         Sensor: Sony IMX480

·         Megapixels: 16 MP

·         Focal Length: 23 mm equivalent

·         Pixel Size: micron

·         Aperture: f/2.4

·         Focus mode: Fixed focus

·         EIS support: Supported

·         Front Camera Video: 1080p video at 60/30 fps, 720p video at 30 fps

·         Front Camera Features: Face Unlock, Screen Flash, Night Mode, Portrait Mode, Pano, Time-lapse, Retouching, Filters



Connectivity

SIM

·         Yes (Dual nano-SIM slot)



LTE/LTE-A

·         4×4 MIMO, Band1/3/4/7/38/40/41/66 4×4 MIMO, other Band: 2×2 MIMO, depending on carrier support



Band

·         2G GSM: 850/900/1800/1900MHz

·         3G WCDMA: Bands 1/2/4/5/6/8/19

·         4G LTE FDD: Bands 1/2/3/4/5/7/8/12/17/18/19/20/26/28/32/66

·         4G LTE TDD: Bands 38/39/40/41

·         5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n26/n28/n38/n40/n41/n66/n77/n78

·         *Network connectivity may vary depending on carrier’s network and related service deployment.



Wi-Fi

·         WiFi2.4G, WiFi5G, WiFi 6 (802.11ax), WiFi 5 (802.11ac), 802.11b/g/a/n, WLAN Display, WLAN tethering, Wi-Fi 2.4GHz 20M, Wi-Fi 2.4GHz 40M, Wi-Fi 5GHz 20M, Wi-Fi 5GHz 40M, Wi-Fi 5GHz 80M, Wi-Fi 5GHz 160M, 2x2 MIMO



Bluetooth

·         Bluetooth 5.4, support SBC/AAC/aptX HD/aptX/LDAC/LHDC 5.0



NFC

·         NFC Enabled



Positioning

·         Satellite Positioning: Single band: GPS, GLONASS, BDS, Galileo, QZSS

·         Other Positioning: Supports A-GNSS assisted positioning, WLAN positioning, cellular network positioning



Sensors

·         Proximity sensor

·         Ambient light sensor

·         E-compass

·         Accelerometer

·         Gyroscope

·         In-display optical fingerprint sensor

·         Infrared remote control



Ports

·         USB 2.0, Type-C

·         Hybrid Slot (Dual Nano-SIM/One Nano-SIM & one MicroSD, up to 1TB)



Buttons

·         Gestures and on-screen navigation support

·         Right: Volume key, Power key



Audio

·         Single bottom-firing speaker

·         Noise cancellation support



Multimedia

Audio Supported Formats

·         Playback: MP3, AAC, AMR, APE, OGG, FLAC, WAV, MIDI

·         Recording: MP3, AAC, WAV



Video Supported Formats

·         Playback: MP4, 3GP, MKV, MOV, AVI, FLV, HEVC, AVC, VP9, VP8, AV1

·         Recording: MP4



Image Supported Formats

·         Playback: JPEG, BMP, PNG, DNG, HEIF, AVIF, WEBP

·         Output: JPEG



What in the Box



·         OnePlus Nord CE5

·         Type-A to C Cable

·         Quick Guide

·         Safety Guide

·         Screen Protector (pre-applied)

·         SIM Tray Ejector



* TRC Approved

*Two-Year Hardware Warranty and Software Warranty
